7mil Aluminum Coated Cloth with Silicone Adhesive


Price per roll:

Width: Rolls per case: Min. Rolls Order: < 1 Case: 1 - 4 Cases: 5 - 9 Cases: 10+ Cases:
1/2" 96 12 $27.92 $23.26 $21.48 $20.68
3/4" 64 8 $34.36 $28.63 $26.43 $25.45
1" 12 6 $42.95 $35.79 $33.04 $31.81
1-1/2" 8 4 $64.43 $53.69 $49.56 $47.72
2" 6 3 $85.90 $71.58 $66.08 $63.63
3" 4 2 $128.85 $107.38 $99.12 $95.44

Custom Sizes Available


Part Number: CO407

Description:  An aluminum foil/glass fabric laminate with a high temperature silicone adhesive. The aluminum foil provides excellent reflective and conductive characteristics in high temperature applications. The silicone adhesive provides excellent adhesion at high temperatures yet will remove cleanly.

Physical Properties:

Adhesive Type: Silicone
Backing Material: Glass/Foil
Adhesive Thickness: 3.5 mil Backing Thickness: 8.5 mil
Elongation: 5% Peel Adhesion: 55 oz./inch width
Max. Operating Temperature: 500 deg F Sizes: 1/2", 3/4", 1", 1-1/2", 2" and 3"

The information on this data sheet is true to the best of our knowledge.  Since the condition, during the use of this product, can vary greatly we recommend the user test the product for their specific application.
